Дополнительные опции
1. Кондиционер
| № | Каталожный номер | Описание | Количество |
| 1 | 263-58-00001 | Strap | 1 |
| 2 | 01580-11008 | Nut M10 | 8 |
| 3 | 263-58-00002 | Compressor Mounting shaft | 2 |
| 4 | 01010-51085 | Bolt M10*85 | 1 |
| 5 | 263-58-06000 | Mounting tube | 1 |
| 6 | 263-58-00003 | Regulation tube | 1 |
| 7 | 263-58-00004 | Mounting shank | 1 |
| 8 | 01010-50830 | Bolt M8*30 | 4 |
| 9 | 01643-30823 | Washer | 6 |
| 10 | 263-58-05000 | Compressor Mounting bracket | 1 |
| 11 | 263-58-01000 | Compressor | 1 |
| 12 | 263-58-08000 | Hose C | 1 |
| 13 | 01643-31032 | Washer 10 | 10 |
| 14 | 263-58-03000 | Condensator | 1 |
| 15 | 01010-51025 | Bolt M10*25 | 4 |
| 16 | 263-58-02000 | Hose A | 1 |
| 17 | 263-58-10000 | Hose D | 1 |
| 18 | 01010-50820 | Bolt M8*20 | 2 |
| 19 | 263-58-09000 | Liquid storage | 1 |
| 20 | 263-58-07000 | Hose B | 1 |
| 21 | 263-58-04000 | Evaporator | 1 |
| 22 | 01010-51035 | Bolt M10*35 | 4 |
| 23 | 01598-11011 | Nut M10 | 2 |
| 24 | 263-58-00007 | Nut | 1 |
| 25 | 263-58-00008 | Nut | 1 |
1а. Кондиционер для модели SR20M-2
| № | Каталожный номер | Описание | Количество |
| 1 | 263-58-00005 | Strap | 1 |
| 2 | 01580-11008 | Nut M10 | 12 |
| 3 | 263-58-00002 | Compressor Mounting shaft | 2 |
| 4 | 01010-51085 | Bolt M10*85 | 1 |
| 5 | 263-58-06000 | Mounting tube | 1 |
| 6 | 263-58-00003 | Regulation tube | 1 |
| 7 | 263-58-00004 | Mounting shank | 1 |
| 8 | 01010-51035 | Bolt M10*35 | 7 |
| 9 | 01643-31032 | Washer | 14 |
| 10 | 263-58-11000 | bracket | 1 |
| 11 | 263-58-01000 | Compressor | 1 |
| 12 | 263-58-08000 | Hose C | 1 |
| 13 | 01643-30823 | Washer | 6 |
| 14 | 263-58-03000 | Condensator | 1 |
| 15 | 01010-51025 | Bolt M10*25 | 4 |
| 16 | 263-58-02000 | Hose A | 1 |
| 17 | 263-58-10000 | Hose D | 1 |
| 18 | 01010-50820 | Bolt M8*20 | 2 |
| 19 | 263-58-09000 | Liquid storage | 1 |
| 20 | 263-58-07000 | Hose B | 1 |
| 21 | 263-58-04000 | Evaporator | 1 |
| 22 | 01598-01011 | Nut | 2 |
| 23 | 263-58-00006 | tray | 1 |
| 24 | 01010-50840 | Bolt M8*40 | 4 |
| 25 | 263-58-00007 | Nut | 1 |
| 26 | 263-58-00008 | Nut | 1 |
2. Бандаж дорожного катка для моделей SR20MP，SR20MP-2
| № | Каталожный номер | Описание | Количество |
| 1 | 263-82-00001 | Bolt | 18 |
| 2 | 263-82-00002 | Nut | 18 |
| 3 | 263-82-01000 | Plate | 1 |
| 4 | 263-82-02000 | Plate | 2 |
